AETA:MultiScoop

Modular multichannel codec with IP, ISDN and AES67, up to 16 audio connections in 3U

Versatility

Ease of use

16 AUDIO CHANNELS

Stéréo

AoIP

: Ethernet

: ISDN

2 year warranty

Firmware Update

Product sheet

User manual

Technologies

Double codec over IP	Double streaming	Packet replication
SIP or Direct RTP	N/ACIP compliant	5A System
HTML server	Multicast	Remote Access
SNMP

Assets

The latest addition to the AETA codec range!

Broadcast audio quality (up to 20 kHz)
Up to 16 audio channels in 3U
Flexible audio interfaces (up to 16 in 3U) : analog, AES3, AES67

Hot-swap modules (sold separately) :
Up to 8 AoIP & ISDN modules (with double mono codec)
Factory SIP accounts included (exclusive for the device, on AETA SIP server)
Up to 2 AES 67/Ravenna modules – Dante compatible
Up to 2 Control modules

Full redundancy: power, control and AES67 modules
Separate audio and control networks for more safety

Easy control and supervision
Full control (including power supplies) from control modules with separate networks
Supplied with Scoop Manager for simplified codecs management
Embedded HTML server for each module
Remote Access : remote access and control via Internet
SNMP

Customization on request

Convenient, robust and secure for multiple audio connections

MultiScoop is the ideal rackmount codec when you need to perform a lot of audio connections.
The device allows up to 16 IP or ISDN connections (mono) in a 3U unit. Audio interfaces allow you to distribute analog audio signals, and also digital audio signals in AES3 or AES67 format.

With MultiScoop, you get all the security you need: hot-swap modules, full redundancy with up to 2 power supplies, 2 control modules on separate networks and even redundancy for AES67 audio distribution, with up to 2 Ravenna AES67 modules.

MultiScoop has also been designed to be easy to use and manage with Scoop Manager software included for free with the device. Scoop Manager provides simplified management of your AETA codecs pool.

Audio Interfaces
